Adding Velocity (needs the EPROM Upgrade)
The Amount of the Envelope gets dependent from the MIDI value for the notes velocity. In this mode neither the sequencer nor the keyboard will work....
huhuh
moetje een eprom upgrade doen om velocity sensitive ..noten te kunne spelen via midi...?
- deze zou ik zelf wel doen ask er eenhad...
3.) Tips regarding the VCF
I strongly recommend to tune the VCFs and the adjust (increase! hehehe...) the resonance of the Filters. This is described on the modification page, since this requires to open the JX-3P, which only should be done by people who can distinguish the tip of a soldering iron from its end ;-)
* Set to exact octave tracking:
The printed symbols show for parameter B3 (VCF tracking) a 3 o'clock position as 100%. This corresponds to a value of 13 on the LED chain, but on my JX-3P this is not the right value. To get the right value, use the following procedure. Use program B1; remove the vibrato (parameter A3 and A10 to Value A=off); raise resonance to maximum; press "Hold"; play all C-keys; now adjust the tracking so far that it sounds like quite good octaves; adjust cutoff-frequency that the filter is one octave over the oszillator; again adjust the tracking; again control the cutoff frequency; check tracking and cutoff until you hear fine octaves which are not dtuned against the DCOs. Again: This needs well adjusted resonance and VCF tune.
4.) Other Tips.
* Noise as modulation source
The parameter B10 provides officially only three waveforms for the LFO, but selecting "D" as value results in a kind of pink noise as modulation signal. This setting may be stored without any problem. The PG-200 won't provide it, since it has only a three way switch.
tsja t schynt idd dat mensen met langer haar liever aan snaren trekken dan de toetsen beroeren ,.....en graag hun drumstellen om ver trappen ...[geld dus niet voor alle "longhairs "]
app. achtig ding [past daarook een pg 200 op?]
