Q. How do I connect the SQ-1 for use with the littleBits Synth Kit?
the littleBits Proto module and a mini-monaural cable
Example
A. To connect the SQ-1's littleBits OUT jack with the littleBits Synth Kit, you'll need the littleBits Proto module and a mini-monaural cable (*).
1) Strip some insulation from the mini-monaural cable.
2) As shown in the illustration to the right, fasten the core and shield of the cable to the terminal screw of the Proto module.
3) Of the Proto module's three jumpers, remove the middle jumper.
4) Set up the littleBits circuit (one example is shown to the right), and connect the Proto module's mini-monaural cable to the SQ-1's littleBits OUT jack.
5) Press the SQ-1's START/STOP button to make the littleBits Synth Kit start playing.
- See more at: http://www.korg.com/us/products/dj/sq_1/faq_tips.php#sthash.LN53FzxD.dpuf
http://www.korg.com/us/products/dj/sq_1/faq_tips.php
the littleBits Proto module and a mini-monaural cable
Example
A. To connect the SQ-1's littleBits OUT jack with the littleBits Synth Kit, you'll need the littleBits Proto module and a mini-monaural cable (*).
1) Strip some insulation from the mini-monaural cable.
2) As shown in the illustration to the right, fasten the core and shield of the cable to the terminal screw of the Proto module.
3) Of the Proto module's three jumpers, remove the middle jumper.
4) Set up the littleBits circuit (one example is shown to the right), and connect the Proto module's mini-monaural cable to the SQ-1's littleBits OUT jack.
5) Press the SQ-1's START/STOP button to make the littleBits Synth Kit start playing.
- See more at: http://www.korg.com/us/products/dj/sq_1/faq_tips.php#sthash.LN53FzxD.dpuf
http://www.korg.com/us/products/dj/sq_1/faq_tips.php
(aansluitingen?)
